AUTOMATEX Automatic Napkin Chain Stitch Hemmer Model: FN-7725- O
Item Number9871
Quantity1
MachineAUTOMATEX Automatic Napkin Chain Stitch Hemmer Model: FN-7725- O
Description1. AUTOMATED UNIT INCLUDES : YOC: 2006 1.1- Double hemming chain stitch section 1.1.1 1- Cradle with electronic edge alignment and end of roll sensor 1.1.2 1- Tension control dancer roller 1.1.3 1- Servo motor notching mechanism for mitered corners 1.1.4 2- Edge trimmers with up to3 " waste capacity 1.1.5 2- Venturi vacuum systems 1.1.6 4- Thread break sensors 1.1.7 2- Hemming folders 1.1.8 1- Pegasus EX 2241 single needle chain stitch 1.1.9 1- Pegasus E 22 L left head single needle chain stitch 1.1.10 2- Synchronized AC motors 1.1.11 1- AC drive nip roller 1.1.12 1- Accumulation station 1.2 Panel Cutter and transfer section 1.2.1 1- Pinch measuring system controlled via Servo motor 1.2.2 1- Panel cutter 1.2.3 1- Servo drive transfer 1.3- Double hemming chain stitch and stacking section 1.3.1 1- Servo drive left and right conveyor systems 1.3.2 2- Downturn belt hemming folders to prepare side hems 1.3.3 4- Thread break detectors 1.3.4 1- Pegasus EX 2241 single needle chain stitch 1.3.5 1- Pegasus E 22 L left head single needle chain stitch 1.3.6 2- Synchronized AC motors 1.3.7 4- Pneumatic scissors type knives to separate thread 1.3.8 2- Retractable hot air nozzles to fuse thread ends 1.3.9 1- Pinch stacker 1.3.10 1- Return bundle conveyor 1.4 Programmable Logic Controller with touch screen operator interface 7. REQUIREMENTS 7.1- The electrical specifications required to run the unit are : 208 volts / 3 phases / 60 Hz / 25 amps 7.2- The air supply requirements for the unit are: 90 psi / 25 cfm 8. SPECIFICATIONS 8.1- Production: 14 (20" x 20") units per minute at 100% efficiency 8.2- Roll diameter: up to 30" 8.3- Finished Length: 1- 24" 8.4- Finished Width: 1- 24" 8.5- Finished Hem : 3/8" 8.6- Stitches per inch : 8 (+0.5) 8.7- Condensed stitch per inch : 12 - 16
AUTOMATEX Automatic Napkin Chain Stitch Hemmer Model: FN-7725- O
AUTOMATEX Automatic Napkin Chain Stitch Hemmer Model: FN-7725- O AUTOMATEX Automatic Napkin Chain Stitch Hemmer Model: FN-7725- O AUTOMATEX Automatic Napkin Chain Stitch Hemmer Model: FN-7725- O
